SOM1028
SOM1028
Two powerful 64-bit Arm V8 cores support real-time processing for industrial control and virtual machines for edge computing in the IoT. The integrated GPU and LCD controller enable Human-Machine Interface (HMI) systems with next-generation interfaces. It also equiped a 4 port Time-Sensitive Networking enabled switch,as well as two CAN interface with CAN-FD capacity.

The SOM1028A systom-on-module for industrial and automotive includes a time-sensitive networking (TSN) -enabled Ethernet switch and Ethernet controllers support converged IT and OT networks.Two powerful 64-bit Arm V8 cores support real-time processing for industrial control and virtual machines for edge computing in the IoT. The integrated GPU and LCD controller enable Human-Machine Interface (HMI) systems with next-generation interfaces.It also equiped a 4 port Time-Sensitive Networking enabled switch,as well as two CAN interface with CAN-FD capacity.To make the Industrial IoT and Industry 4.0 a reality, manufacturers must interconnect operations technology (OT), such as manufacturing and automation systems, to their information technology (IT), including inventory, logistics, and customer relationship management systems. Enabling flow of information between these two domains will increase efficiency and reduce product delivery times.



TARGET APPLICATIONS

  • Control and factory automation

           robotics controllers,I/O controllers, motion controllers

  • Transportation

          Gateways, HMI, embedded controllers for mass transit and railways

  • IoT gateways
  • Networking gateways
  • Programmable logic controllers (PLCs)
  • Industrial PCs
  • Avionics



CPU

  • Quad 64-bit ARM V8 Cortex®-A72 cores running up to  1500 MHz
    • 32-Kbyte L1 Instruction cache
    • 32-Kbyte L1 Data cache
    • 1024-Kbyte Level 2 cache with ECC

Interfaces

  • 4x Gigabit Ethernet with TSN switch
  • 2x USB 3.0/2.0 Dual-Role with PHY
  • 2x PCIe Gen 3
  • 1x SDIO 3.0
  • 2 × CAN controllers supporting CAN FD protocol
  • 3 × SPI
  • 8 x I2C
  • 6 × I2S
  • 2 x UART
  • 6 xLPUART
  • DP 1.4
  • RGMII
  • SGMII

Graphics and multimedia

  • 3D GPU: Supports OpenGL 3.0, 2.1; OpenGL ES 3.1, 3.0, 2.0, and 1.1; OpenCL 1.2 Full Profile and 1.1; OpenVG 1.1; and Vulkan

Complicances

Software

All prices blow are specified in USD.

Prices are periodically updated according to variations in component costs. Prices are subject to change without advance notice.

P/N template: SOM1028-AI-2048M-16G-Q16M

Where:

A: hardware edition

I: industry grade(-40 - 85 dgree),E: consumer grade(0-70 dgree)

2018M: DDR4 size

16G: eMMC

Q16M: QSPI FLASH 16MB or other size

CRYPTO: ATECC608A

Default configuration P/N:             SOM1028-AE-2048M-8G-Q16M      PRICE: $149

Advance configuration P/N:           SOM1028-AE-4096M-16G-Q16M      PRICE: $199

Industry  configuration P/N:           SOM1028-AI-2048M-8G-Q16M        PRICE: $199



​===================================================================================

Note：Customizations accepted,please contact  sales@OpenEmbed.com for other configrations.

All SKUs include:

RTC : real-time clock

ECC : DDR4 with Error Correcting Code

Optional:

Encryp : Encryption chip ATECC608A

eMMC Size: From 8GB to 64GB

QSPI FLASH size: From 8MB to 64MB





Other Quantity Orders:

Pricing is specified for 100-unit orders.Multiply the unit price by the factor to calculate the price for another quantity :

Qty Factor
10K contact us
1K 0.85
500 0.9
100 1.0
10 1.2
1 1.5
